Fisher-Price P4266 User Manual
Page 12
12
P4266pr-0920
• Insert a #8 x ¾" screw into the hole in the shock and tighten.
Note: Do not insert a screw into the upper portion of the shock
in this step. A screw will be assembled in this location in step 24.
• Repeat steps 17 and 18 to assemble the other shock to the
other side of the vehicle.
18
Screw
DO NOT insert
a screw here.
17
• Insert eight #8 x ¾" black screws into the tail and tighten.
16
• First, fit the bottom of a shock into the slot next to the tail.
• Then, slide the top of the shock onto the post on the tail.
Shock
Post
Slot
SIDE VIEW
• Fit the tail into the slots in the back end of the vehicle frame.
15
Tail
FRONT VIEW
