11 P4266pr-0920
Front Hubcap
14
• Fit the tabs on the front hubcap into the slots in the front
wheel. Push to "snap" into place.
• Repeat steps 9-14 to assemble the remaining bushing,
front wheel, rim and front hubcap to the other front axle.
• Slide a rim, indented side out, onto the front axle.
Rim
Lock Nut
• Fit a lock nut onto the end of the front axle and tighten with
the assembly wrench.
IMPORTANT! Fully tighten the lock nut with the included
assembly wrench.
• Test to be sure the wheel spins. Lift the front end of the
vehicle up slightly and turn the wheel. It should spin freely.
• If the wheel does not spin freely, use the assembly wrench
to loosen the lock nut a 1 /
4
" turn. Spin the wheel again and
loosen more, if necessary.
12
13
11
Assembly
Wrench
