SON
Adjust video offset channel 0-3 value 0 – 255
SOA
Adjust video offset all channel value value 0 – 255
SGN
Adjust video gain channel 0-3 value 0 – 1023
SGA
Adjust video gain all channel value 0 – 1023
TDI
Set number of TDI stages
2K 4K
1 24 1 4
2 32 2 16
3 48 3 32
4 64 4 64
5 96 5 96
3.5 Camera Command Summary
Command Definition Summary
RSH Reboot System Hard Hard reboot of camera
RSS Reset Command Logic reset of camera
INQ Inquiry Shows what camera is used
VER Version Shows current software
SLR Set Line Rate This function allows line rate change
CPO Calibrate Pixel Offset This function performs correction of pixel offset
CPG Calibrate Pixel gain This function performs correction of pixel gain
VOM Voltage monitoring This function shows internal voltages
TSB Temperature Sensor Board This function shows temp. of sensor board
SSM Set Sync Mode This function allows user to select sync mode
SCM Select Correction Mode This function allows user to select correction mode
STP Select Test Pattern This function allows user to select test pattern
CBR Change Baud rate This function allows user to select baud rate
LED Light Emitting Diode Change LED state
Fairchild Imaging • CAM/CCD 2KCL.TDI & CAM/CCD-4KCL.TDI Line Scan Camera User’s Manual • Rev C• 20 of 30
