1.2 QUADRA
1
2 5 3 4
N7215V
A = 1162 mm
B = 351 mm
N7214V
1180 +1
0
369
+1 0
1162
351
+1 0
9
1.5
R10.5
+1
0
1
2 5 3
N7211V
A = 862 mm
B = 351 mm
N7211V
369
+1 0
351
+1 0
R10.5
9 1.5
926 +1
0
908 +1
0
1
3
N7221V
A = 309 mm
B = 454 mm
N7221V
309 +1
0
323 +1
0
R11
468
+1 0
454
+1 0
7
1.5
