Fuse/Relay
Location
Fuse Amp
Rating
Description
12
10A*
Rear Wipers
13
—
Not Used
14
—
Not Used
15
10A*
Running Board Lamps
16
—
Not Used
17
—
Not Used
18
15A*
Powertrain Control Module, Fuel Injectors,
Fuel Pump, Mass Air Flow Sensor
19
10A*
Trailer Tow Stop and Right Turn Lamp
20
10A*
Trailer Tow Stop and Left Turn Lamp
21
—
Not Used
22
—
Not Used
23
15A*
Powertrain Control Module, HEGO Sensors,
Canister Vent
24
15A*
Powertrain C ontrol Module, Automatic
Transmission, CMS Sensor
101
30A**
Trailer Tow Battery Charge
102
50A**
Four Wheel Antilock Brake Module
103
50A**
Junction Block Battery Feed
104
30A**
4x4 Shift Motor & Clutch
105
40A**
Climate Control Front Blower
106
—
Not Used
107
—
Not Used
108
30A**
Trailer Tow Electric Brake
109
50A**
Air Suspension Compressor
110
30A**
Moonroof, Flip Windows and Heated Seats
111
50A**
Ignition Switch Battery Feed (Start Circuit)
112
30A**
Drivers Power Seat, Adjustable Pedals
113
50A**
Ignition Switch Battery Feed (Run and
Accessory Circuits)
114
30A**
Climate Control Auxiliary Blower
115
—
Not Used
