SETUP

EN

– 7 –

Playing 2 Channel Analog Audio

Playing Multi Channel Digital Audio

AUDIO OUT

DIGITAL AUDIO OUT

SETUP > QUICK >

DOLBY DIGITAL

Connecting to a Dolby Digital decoder
for Dolby Digital audio output.

BITSTREAM

Connecting to other device (an MD deck
or DAT deck etc.) without Dolby Digital
decoder.

PCM

Connection to an Audio System

* To complete these settings, refer to pages 20-21.

Note:

• The audio source on a disc in a Dolby Digital multi channel surround

format cannot be recorded as digital sound by an MD or DAT deck.

• By hooking this unit up to a Dolby Digital decoder, you can enjoy

high-quality Dolby Digital multi channel surround sound as heard in the
movie theaters.

• Playing back a DVD using incorrect settings may generate noise distor-

tion and may also damage the speakers.

Connection to a Cable/Satellite Box

Using the unit with a cable/satellite box

1. Connect an RCA audio and video cables to the audio and

video output jacks of your cable/satellite box and to the audio
and video input jacks at the rear of the unit.

2. Press

[INPUT SELECT]

on your remote control until “L1” is

displayed on your TV.

Special note when connected to a cable/satellite box:

Only the active channel on your cable/satellite box may be
viewed or recorded when connected to this unit.
Do not change channels during a recording.
You cannot record on channel while viewing another.

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

VCR

DVD/VCR

S-VIDEO

OUT

COMPONENT

VIDEO OUT

VIDEO IN

AUDIO OUT

VIDEO OUT

L

L

Y

R

AUDIO IN

R

R

AUDIO IN

VIDEO IN

L

R

CB

/

PB

CR/

PR

AUDIO IN

VIDEO IN

VCR

DVD/VCR

AUDIO OUT

L

VIDEO OUT

R

VIDEO IN

AUDIO IN

L

R

AUDIO OUT

VIDEO OUT

L

R

Audio

This unit

RCA audio cable

RCA video cable

RCA audio cable

RCA video cable

rear of TV

rear of the unit

external tuner

(cable/satellite box)

L1:

Rear panel terminals

L2:

Front panel terminals

Refer to “Front & Rear Terminals” on page 9 for more information.

L1

Note:

• Your cable/satellite box can be accessed only by connecting it to L1

(rear panel jacks) of the unit. Even if the unit is turned off, the signal
from the external tuner is output to the TV through the unit.

Connection

Setting

L

R

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

VCR

DVD/VCR

S-VIDEO

OUT

COMPONENT

VIDEO OUT

AUDIO IN

VIDEO IN

AUDIO OUT

VIDEO OUT

L

L

Y

R

R

CB

/

PB

CR/

PR

VCR

AUDIO IN

VIDEO IN

DIGITAL

AUDIO OUT

COAXIAL

VCR

DVD/VCR

AUDIO OUT

L

R

AUDIO

OUT

DVD

L

R

analog audio
input jacks

RCA audio cable

digital audio
input jack

digital audio coaxial cable

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

S-VIDEO

OUT

COMPONENT

VIDEO OUT

COAXIAL

stereo system

Dolby Digital decoder,

MD deck or DAT deck

or
