Setup, Installing the batteries for the remote control, Remote control – FUNAI DV220TT8 User Manual

Page 10

SETUP

– 10 –

POWER

OPEN/CLOSE

DISPLAY

VCR

DVD

MODE

TRACKING

PLAY

STOP

REC/OTR

SKIP

PAUSE

TOP MENU

AUDIO

SETUP

MODE

ZOOM

ANGLE

SUBTITLE

ENTER

REPEAT

A-B

SPEED

T-SET

+10

RETURN

CLEAR/

C. RESET

INPUT

SELECT

Installing the Batteries for
the Remote Control

Install the batteries (AA x 2) matching
the polarity indicated inside battery
compartment of the remote control.

Keep in mind the following when using the
remote control:
• Make sure that there are no obstacles

between the remote control and the infra-
red sensor window on the unit.

• The maximum operable ranges from the

unit are as follows.

- Line of sight: approx. 23 feet (7m)
- Either side of center:

approx. 16 feet (5m) within 30°

- Above: approx. 16 feet (5m) within 15°
- Below: approx. 10 feet (3m) within 30°

Remote Control

Note:

• Do not mix alkaline and manganese batteries.
• Do not mix old and new batteries.
• If you turn off this unit, [OPEN/CLOSE A] on the

remote control is not available.
Be sure to use [OPEN/CLOSE A] or
[STOP/EJECT C A] on the unit.

DVD mode

VCR mode

+10

• To select chapter or title

directly.

• To select track or file directly.

• To search forward/backward

through a disc.

• To begin slow forward/reverse

playback in the pause mode.

• To search forward/backward

through a disc.

• To forward/backward a tape.
• To begin slow forward

playback in the pause mode.

A-B

• To repeat between your chosen

point of A and B.

• To repeat between your

chosen point of A and B. (CD)

ANGLE

• To select camera angles on a

disc.

AUDIO

• To select audio languages on a

disc.

• To select “STEREO”, “L-ch” or

“R-ch”. (CD)

CLEAR/

C. RESET

• To clear the markers.
• To clear numbers entered

incorrectly.

• To cancel the point for A-B

repeat.

• To clear the markers. (CD)
• To remove status number in

program input.

• To clear numbers entered

incorrectly.

• To cancel the point for A-B

repeat. (CD)

• To exit the VCR menu.
• To reset the tape counter.

DISPLAY

• To display the current disc

mode.

• To display the current disc

mode.

• To display the current time,

tape counter, and L1 or L2.

DVD

• To select DVD output mode.
• To activate DVD mode.

• To select the DVD output mode.
• To activate DVD mode.

ENTER

• To move the cursor and deter-

mine its position.

• To move the cursor and deter-

mine its position.

• To select an item on

the VCR menu.

• To advance to the

next VCR menu.

• To go back one step

during clock and
timer programming.

INPUT

SELECT

• To select input “L1” or “L2”.

• To call up the disc menu on a

disc.

• To call up the file list. (MP3)

MODE

• To set black level on/off.
• To set virtual surround on/off.

• To arrange the playing order or

play randomly.

• To set virtual surround on/off.

OPEN/CLOSE

• To open or close the disc tray.

• To eject the cassette tape from

the cassette compartment.

PAUSE

• To pause disc playback.
• To advance playback one frame

at a time.

• To pause disc playback.

• To pause tape playback or

recording.

• To advance playback one frame

at a time.

PLAY

• To begin disc playback.

• To begin tape playback.

POWER

• To turn the unit on/off.

REC/OTR

• To start recording or one-touch

timer recording (OTR).

REPEAT

• To play back a chapter or title

repeatedly.

• To play back a track or disc

repeatedly. (CD)

• To play back a file, folder or

disc repeatedly. (MP3)

• To select the repeat mode on/

off.

RETURN

• To return to the previous

operation in menu.

• To return to the previous

operation in menu.

MODE

• To search chapter, title or time.
• To set or search the markers.

• To search track.
• To search time. (CD)
• To set or search the markers. (CD)

• To call up the index or time

search menu.

SETUP

• To call up the DVD menu.

• To call up the VCR menu.

SKIP

• To skip chapters or titles.

• To skip tracks or files.

SPEED

• To select the recording speed.

STOP

• To stop playback.

• To stop playback or recording.

SUBTITLE

• To select subtitles on a disc.

TOP MENU

• To call up the top menu on a

disc.

• To return to the top file of the

highest hierarchy in the pro-
gram and file list. (MP3)

TRACKING

• To adjust the tracking manually

during playback.

T-SET

• To put the VCR into standby

mode for a timer recording.

VCR

• To select the VCR output mode.
• To activate VCR mode.

ZOOM

• To magnify part of a picture.

(2x/4x)

Button
(Alphabetical order)

Media
