1.3 Power Requirements
C141-E192-01EN 1-5
Table 1.1 lists the formatted capacity, number of logical cylinders, number
of heads, and number of sectors of every model for which the CHS mode
has been selected using the BIOS setup utility on the host.
Table 1.1 Specifications (2/2)
Model Capacity (*1) No. of Cylinder No. of Heads No. of Sectors
MHT2080AT 8.45 GB 16,383 16 63
MHT2060AT 8.45 GB 16,383 16 63
MHT2040AT 8.45 GB 16,383 16 63
MHT2030AT 8.45 GB 16,383 16 63
MHT2020AT 8.45 GB 16,383 16 63
*1 On using for the units of BIOS parameter.
1.2.2 Model and product number
Table 1.2 lists the model names and product numbers of the MHT Series.
Table 1.2 Model names and product numbers
Model Name
Capacity
(user area)
Mounting screw Order No.
MHT2080AT 80 GB M3 depth 3 CA06297-B048
MHT2060AT 60 GB M3 depth 3 CA06297-B046
MHT2040AT 40 GB M3 depth 3 CA06297-B024
MHT2030AT 30 GB M3 depth 3 CA06297-B023
MHT2020AT 20 GB M3 depth 3 CA06297-B022
1.3 Power Requirements
(1) Input Voltage
• + 5 V ± 5 %
(2) Ripple
+5 V
Maximum 100 mV (peak to peak)
Frequency DC to 1 MHz
