2-5
ITEM PART # COMPONENT
1 806-3853SP Door Assembly, 18.66-inch x 19.85-inch (does not include handle)
806-4487SP Door Pin Assembly
826-1343 Spring, Door Hinge (Pkg. of 10)
A 810-1402 Handle, Wireform Door
B 210-9214 Handle, Eurolook Door
2 809-0193 Washer, ¼-inch Nylon Flat
3 826-1371 Screw, #8 x ½-inch Drill Point Hex Head Zinc Plated (Pkg. of 25)
4 810-1508 Hinge, Universal Door
5 806-5522SP Base Assembly, GBC/GC
806-5209SP Leg Pad Assembly
900-4655 Channel, Front or Rear Base
900-7528 Channel, Left or Right Base
6 900-7912 Shield, GBC/GC Vapor (See NOTE below)
* 200-5095 Shield, Vapor (for units with manual water fill)
7 826-1115 Leg Assembly w/Mounting Hardware
8 810-1105 Magnet, Door
9 Side, Left or Right Cabinet
910-7377 Stainless Steel
900-7377 Enameled Mild Steel
10 816-0091 Grommet, 1¼-inch Drain (See NOTE below)
11 900-4651 Shield, Control Box Water
12 900-1552 Gusset
13 900-1940 Bracket, GBC/GC Control Box Mounting
14 900-1759 Bracket, Pot Hold-Down
15 900-1932 Retainer, Flue Insulation
16 900-4654 Brace, Front or Rear Top
17 824-0434 Topcap, GBC/GC
18 809-0266 Screw, #10 x ½-inch Philips Truss Head Zinc Plated
19 806-5260SP Frame Assembly, Control Panel
20 816-0158 Insulation, 18.25-inch x 10.7-inch x .25-inch Cabinet Back
21 900-4521 Retainer, Cabinet Back Insulation
22 806-6007SP Flue Cap and Insulation Assembly
823-2105 Flue Cap
816-0169 Insulation, 8.12-inch x 18-inch x .25-inch Flue Cap
910-1181 Retainer, Flue Cap Insulation
809-0053 Nut, 10-32 Hex
23 826-1351 Nut Retainer, ¼-20 (Nutsert) (Pkg. of 10)
24 900-7379SP Back, GBC/GC Cabinet
25 812-1141 Insulation, Cabinet Back
26 826-1374 Screw, #10 x ½-inch Hex Head (Pkg. of 25)
27 812-1142 Insulation, Cabinet Back
28 900-4645 Shield, Basket Lift Heat (used on GBC units only)
* Not illustrated.
NOTE: Order Moisture Control Kit 826-1492 to retrofit earlier units, which were not equipped with vapor shields. The kit contains
items 6 and 10, mounting screws, and installation instructions.
