Page 13

Assembly

• Fit one of the side tabs on the hood into the slot in the

vehicle body.

• While bending the hood slightly, fit the other side tab into

the corresponding slot on the vehicle body.

Hood

Side
Tab

Slot

• Fit the tabs on the battery clamp cap into the slots in the

battery clamp unit.

• Press firmly to “snap” the battery clamp cap tabs in the

battery clamp unit slots.

Battery Clamp Cap

Tab

Slot

Battery
Clamp
Unit

Steering
Wheel

Notch

Steering
Wheel
Cap

• Align the notch in the side of the steering wheel cap

with the tab in the center of the steering wheel. Fit the
steering wheel cap into the steering wheel.

• Insert two #8 -18 x 1" screws into the steering wheel

cap and tighten the screw with a Phillips screwdriver.
Do not over-tighten.

• Position the steering wheel upright, so that the spokes

form a "Y".

• Fit the steering wheel onto the steering column. Make

sure the neck of the steering wheel fits into the hole in
the dash.

• Fit a cap nut onto the end of the steering column.

• Tap the cap nut with a hammer to secure it on the

end of the steering column.

Hint: You may want the help of another adult to support
the steering column while you tap the cap nut with
the hammer.

Steering
Wheel

Steering
Column

“UP”

Cap
Nut
