10
Assembly
• Press firmly above one of the rear tabs to snap it into the
slot in the vehicle body.
IMPORTANT! While snapping the rear tab into the slot,
push on the side of the cab to prevent it from bowing. Make
sure that the cab side tabs stay aligned in the vehicle slots.
Cab
PRESS DOWN HERE
To Snap Rear Tab
PUSH
HERE
To Keep
in Place
• Position the three front tabs on the cab into the slots in
the vehicle body. DO NOT snap the front tabs into the
slots in the vehicle body.
• Position the side and rear tabs on both sides of the cab
in the corresponding slots the vehicle body. DO NOT
snap the side and rear tabs into the slots in the
vehicle body.
Cab
Rear
Tabs
Side Tabs
Front
Tabs
• Press down above the cab side tabs while pulling
up on the front wheel well to snap the side tabs into
the slots.
• Repeat steps 6 and 7 to snap the rear and side tabs
on the other side of the cab into the slots in the
vehicle body.
PRESS
DOWN HERE
To Snap
Side Tabs
PULL UP
• Insert two #8 - 18 x 1 3 /
4
" screws through the holes in the
front bumper and into the vehicle body. Tighten the
screws using a Phillips screwdriver. Do not over-tighten.
5
6
7
4
