Caution:If, after completing these steps, you are unsure that unit is
properly installed, contact a qualified installer.To ensure that
your washer is properly installed, it is recommended that it
be installed by a certified installer.

Water Inlet

Water Supply Hose

Goose Neck

Hose Bend

Drain Hose

4. Install the drain hose to the side of the washer using the drain hose
damp provided. The drain hose must be placed into a drain pipe or sink
at least 1 1/2inches in diameter. Use the goose neck to the hose in
place. To avoid possible water back up, the drain hose must reach a
minimum height of 1000mm and a maximum height of 1500mm.

5.Plug the washer into a regular 220-240Volt/50Hz,10Amps outlet.

Note :Carefully inspect all around the machine and at the back for any

leaks, and tighten any loose connections.
