18
Figure 21
NOTE: IF ANY OF THE ORIGINAL
WIRE AS SUPPLIED WITH THE
APPLIANCE MUST BE REPLACED,
IT MUST BE REPLACED WITH TYPE
105
• C RATED WIRE.
JUNCTION BOX JUNCTION BOX
FAN
BLUE
BROWN
YELLOW/GREEN
BLUE
BRN
YW/GR
BLK
BLK
TEMP. SENSOR
SWITCH
TEMP. SENSOR
SWITCH
BLK
BLK
SPEED CONTROL SPEED CONTROL
FAN WIRING DIAGRAM FAN WIRING DIAGRAM
BLK
BLK
YELLOW/GRN
YELLOW/GRN
BLUE
BRN
BRN
BLUE
GRD
BLUE
JUNCTION BOX DETAIL JUNCTION BOX DETAIL
FAN FAN
TEMPERATURE
SENSOR SWITCH
TEMPERATURE
SENSOR SWITCH
FAN SPEED
CONTROL
FAN SPEED
CONTROL
JUNCTION BOX JUNCTION BOX
NOTE: IF THE SUPPLY CORD IS DAMAGED, IT
MUST BE REPLACED BY THE MANUFACTURER,
AN AUTHORIZED SERVICE AGENT, OR A SIMI-
LARLY QUALIFIED PERSON IN ORDER TO AVOID
A HAZARD.
