User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 43.2cm(17.0")
Pixel pitch 0.264mm(H) x 0.264mm(V)
LCD Panel Brightness 250cd/m 2 (Typical)
Contrast 450:1(Typical)
Viewable angle 140 ° (H) 130° (V)
Response time 12 ms
Video
R,G,B Analog Interface
Digital (Dual-Input Model) H/V TTL
Input H-Frequency 31KHz – 80KHz
V-Frequency 55-75Hz
Display Colors 16.2M Colors
Dot Clock 135MHz
Max. Resolution 1280 x 1024 @75Hz
Plug & Play VESA DDC2B TM
ON Mode ≤ 42W
EPA ENERGY STAR ®
OFF Mode ≤ 3W
Audio output Rated Power 1W rms (Per channel)
Input Connector
D-Sub 15pin
DVI-D 24pin (Dual-Input Model)
Maximum Screen Size
Hor. : 337.92mm
Ver. : 270.34mm
Power Source 90~264VAC,47~63HZ
Environmental
Considerations
Operating Temp: 5° to 40°C
Storage Temp.: -20° to 65°C
Operating Humidity: 10% to 85%
Dimensions 403(W)×397(H)×180(D) mm
Weight (GW/NW) 5.6 Kg / 4.4 Kg
Regulatory Compliance
CCC, UL,VCCI,C-TICK, TUV, BSMI, CE,
CB,FCC,CUL,TCO99 (for optional model)
22
