Panasonic TH-86CQE1W 86" Class 4K UHD Commercial Monitor - Manual (Page 33)

English - 32 -
Scheduler Settings
Using the scheduler options you can set the unit to turn on automatically at defined time
intervals with the defined input source setting on the desired days of the week. Press
ENTER to open the Scheduler Settings menu screen. You can set up to 4 different
schedulers.
Highlight the first checkbox of the desired scheduler option and check it by pressing
the ENTER button. Now you will be able to define a time for the Display to be turned on
automatically. Highlight the time box next to the first checkbox and press the ENTER
button, then use the directional and numeric buttons on the remote to set a time. Press
the ENTER button again when you are done.
Perform the same steps to set a time for the Display to turn off.
You can also define a source for your scheduler. Highlight the box located under the
Source tab for your scheduler option and press the ENTER button, then set as desired
using the Left/Right directional buttons. If the Source option is set as Last Source ,
the input source will not be changed at the power-up. If the Source option is set as
USB , the media files in the connected USB device will be played back automatically as
explained in the section entitled ‘ USB Auto Play Feature ’.
If the Source option is set as
USB, the media files in the connected USB device will be played back automatically as
explained in the section entitled ‘USB Auto Play Feature’.
In this scenario, if source USB is selected in the Scheduler Settings menu,
the scheduler will show playlist options. The user can create 3 different playlists.
When the scheduler is activated, the playlist scenario is started.
During the autoplay, the selected playlist is checked first.
If the selected playlist is not available in USB, the default playlist file is checked.
If the default playlist file is not found, it works just like the USB Auto play scenario.
When the "Playlist Selection" menu is selected, the operation is performed according
to the file name described below.
File name (selection item):
playlist.txt(Default), playlist1.txt(Playlist1), playlist2.txt(Playlist2), playlist3.txt(Playlist3)
Lastly, you can select the week day/s for your scheduler setting to be activated. Highlight
the checkbox under the desired day tab and press ENTER to check. Highlight and press
ENTER a second time to uncheck a box. The scheduler will be active on the checked
days of the week.
You can also set a backlight scheduler. After setting the
On , Off , Source and day options
highlight the checkbox under the Backlight column and press ENTER . The checkbox
will be checked and backlight level setting screen will be displayed. Set On value and
Off value using the sliders and then press ENTER to save. Mind that, in case you set
a backlight scheduler, the display will not be turned on or off, only the backlight values
will be changed at defined time interval. If Source option is set as Last Source the
backlight settings will be applied to all sources, otherwise the settings will be applied
to the selected source only.
Press the
Green button on the main scheduler screen to save settings when complete.
Note: Only when the unit is turned on by the schedule function, it will be automatically turned
off at the Off time.
Link options
Press ENTER to open the link options menu screen. Open browser initial page and NTP
server link preferences can be configured using the related options.
Volume Settings Press ENTER to see available menu options.
Reset to Default
Values
Highlight this option and press the ENTER button on the remote to return the Display
to default settings.
Shipping
Highlight and press ENTER to perform Shipping and reset all settings to factory settings.
You will need to enter the correct PIN to carry out this operation.
Note: Enter the PIN you have defined during the First Time Installation process.
