C2253M (1/11) 3
Description
The WMVE-SR and WMVE-WT are environmental wall mounts that can be installed directly to a wall or
any vertical surface. Power and video wiring can be easily routed through the back of the mounts or
through the conduit access located on the bottom of the mount arms. The wall mounts can also be pole
mounted using a PA101 pole mount adapter.
MODELS
WMVE-SR Light gray wall mount specifically designed for use with the IM-VEPM, IE-P, and
Camclosure
® 2 Series pendant mount adapters.
WMVE-WT White wall mount specifically designed for use with the ID-P pendant mount adapter.
PARTS LIST
The following installation tools and parts are supplied:
USER SUPPLIED PARTS LIST
Qty Description
1 WMVE-SR/WMVE-WT wall mount
1 Tube of anti-seize lubricant
1 Installation manual
Qty Description
1 Pendant mount adapter
1 Wrench, 5/64-inch, hex Allen
2 to 4 Fasteners, 1/4-inch, of appropriate type based on installation
