Model identification 1. model identification – SAF-HOLLAND XL-FW10049OM AL Aluminum NoLube Series Fifth Wheels User Manual
Page 3
3
XL-FW10049OM-en-US Rev A 11-10 Amendments and Errors Reserved. © SAF-HOLLAND, Inc.
Model Identification
1. Model Identification
Fifth wheel serial tags are located on the
left side of the fifth wheel top plate above
the fifth wheel bracket pin, or on the
pickup ramps as shown (Figure 1).
The part number and serial number are
listed on the tag as shown (Figure 2).
Figure 1
Figure 2
