Tl liftgate terminology – SAF-HOLLAND XL-TG10150UD TL and TG Series Liftgates User Manual
Page 8
8
XL-TG10150UD-en-US Rev B · 2013-05-23 · Amendments and errors reserved. © SAF-HOLLAND, Inc.
TL Liftgate Terminology
ITEM
DESCRIPTION
1
Cart Stops
2
Inner Platform
3
Outer Platform
4
Adjusting Bolts
5
Torsion Spring
6
Compression Member
7
Roller Opener
8
Lift Frame
9
Lift Cylinder
ITEM
DESCRIPTION
10
Side Steps
11
Pump Box Mount
12
Pump Box
13
Travel Latch
14
Main Tube
15
Attaching Plates
16
Deck Extension
17
Control Station
12
15
16
11
10
9
6
4
3
1
2
5
7
13
17
8
14
