Introduction
This manual provides you with the information necessary for
the care, maintenance, inspection, and safe operation of the
SAF-HOLLAND TL and TG Series Liftgate.
NOTE: For liftgate components replacement, contact
SAF-HOLLAND Customer Service at:
U.S. 888-396-6501
Canada 800-503-9847
Warranty
Refer to the complete warranty for the country in which
the product will be used. A copy of the warranty certificate
is included with the product as well as on the SAF-HOLLAND
website (www.safholland.us and www.safholland.ca). It may
also be ordered directly from SAF-HOLLAND; the address is
shown on the back cover.
Notes, Cautions, and Warnings
You must read and understand all of the safety procedures presented
in this manual before operating or starting any work on the liftgate.
NOTE: In the United States, workshop safety requirements
are defined by federal and/or state Occupational
Safety and Health Act. Equivalent laws may exist
in other countries. This manual is written based
on the assumption that OSHA or other applicable
employee safety regulations are followed by the
location where work is performed.
Proper tools must be used to perform the maintenance and
repair procedures described in this manual. Many of these
procedures may require special tools.
Contents Page
Introduction ......................................................................... 3
Warranty .............................................................................. 3
Notes, Cautions, and Warnings ............................................. 3
Section 1 – General Safety Precautions ................................ 4
Section 2 – Model and Serial Number .................................. 6
Section 3 – Decal Part Numbers ........................................... 7
TL Series Terminology ........................................................... 8
TG Series Terminology .......................................................... 9
Section 4 – Pre-Operation Information ............................... 10
Section 5 – Control Switch Operation ................................. 10
Section 6 – Raising or Lowering the Platform ..................... 11
Contents Page
Section 7 – Unfolding the Platform .................................... 12
Section 8 – Foot Pedal Opener Operation ........................... 14
Section 9 – Platform Loading ............................................. 15
Section 10 – Stowing the Platform ..................................... 18
Section 11 – Filling the Hydraulic Reservoir ........................ 20
Section 12 – Routine Service and Inspection....................... 21
Section 13 – Troubleshooting ............................................. 22
Section 14 – Pump Hydraulic and Electrical Diagrams ......... 24
Section 15 – Pump Hydraulic and Electrical Schematic........ 25
IMPORTANT: Read this manual before using this
product. Keep this manual in a safe
location for future reference.
Failure to follow the instructions and
safety precautions in this manual can
result in death or serious injury.
Throughout this manual, you will notice the terms
“NOTE,” “IMPORTANT,” “CAUTION,” and “WARNING”
followed by useful product information. So that you may
better understand the manual, those terms are as follows:
NOTE: Includes additional information to enable
accurate and easy performance of procedures.
IMPORTANT: Includes additional information that if
not followed could lead to hindered
product performance.
Used without the safety alert symbol,
indicates a potentially hazardous situation
which, if not avoided, could result in
property damage.
Indicates a potentially hazardous situation
which, if not avoided, could result in minor
or moderate injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in death
or serious injury.
