Insinger, Part 5 electrical schematics & replacement, 6 and 18-6c – Insinger Commander 18-6VG User Manual
Page 15
®
Commander18_6VGAddendumTM09
www.insingermachine.com 800-344-4802
PART 5 ELECTRICAL SCHEMATICS & REPLACEMENT
13
14
6
10
12
11
1
7
3
13
5
4
8
9
EXPLODED VIEW
2
16
15
17
1
1
A
2383
08.07.09
09.18.09
2397
B
18-6 and 18-6C
17
1564-55
EXHAUST DAMPER FRAME WELD
1
16
D309C-EF-3H
SET SCREW 10-32 X 3/8 CUP POINT
4
15
1564-26
EXHAUST DAMPER REAR COVER
1
14
1564-24
EXHAUST DAMPER COVER WELD
1
13
D3150
HAIRPIN 3/16
6
12
D313C-E1
#10 STD WASHER
6
11
D3147
THRUST BEARING 3/16 BORE
4
10
1564-23
EXHAUST DAMPER LINKAGE
2
9
1564-50
DAMPER PIN 3/16 X 7.25
1
8
D3155
SOLENOID 1 INCH TRAVEL 240V
1
7
D3152
PIN 3/16 X 1
2
6
1564-21
EXHAUST DAMPER CRANK
2
5
1564-18
EXHAUST DAMPER GASKET
2
4
1564-20
EXHAUST DAMPER PLATE
1
3
1564-19
EXHAUST DAMPER SHAFT
1
2
D3141
THRUST BEARING 7/16, NYLON
2
1
1564-13
HOOD EXHAUST BOX WELD
1
ITEM NO.
PART NO.
DESCRIPTION
QTY.
D
C
B
A
B
C
D
6
7
8
7
6
5
4
3
2
1
-
WEIGHT: 9.16 LBS
5
4
3
2
1
A
USED ON
DWG. NO.
1564-12
ECN NO
DATE
.XX ± .01
DECIMALS
SPECIFIED
OTHERWISE
UNLESS
ANGLES ±1/2°
.XXX ± .005
FRACTIONS ±1/64
MAT'L
TOLERANCES
NEXT ASSY
SCALE: 1:4
REQ'D
REV
DWG SIZE
B
DRWN/DATE
FINISH: -
FAX (215) 624-6966
(215) 624-4800
Philadelphia, PA 19135
JJB/DBC
4.15.09/5.11.09
VAPOR GUARD
1
1564-1
FILE: PARTS\1564-12
Insinger
TITLE
-
HOOD DAMPER ASSY
PROGRAM No.:
BLANK SIZE :
SHEET
OF
THE INFORMATION ON THIS DRAWING IS THE PROPRIETARY PROPERTY OF INSINGER MACHINE COMPANY AND MAY NOT BE DISCLOSED TO ANY THIRD PARTY WHATSOEVER FOR ANY PURPOSE INCLUDING, BUT NOT LIMITED TO, THE COPYING OF THIS INFORMATION FOR USE IN MANUFACTURING OF A SIMILAR OR IDENTICAL PART, COMPONENT, OR SYSTEM. ANY VIOLATION OF THE PROPRIETARY RIGHTS OF INSINGER MACHINE COMPANY SHALL SUBJECT THE PARTY RESPONSIBLE TO APPROPRIATE LEGAL ACTION.
REV
B
