Page 10
eZ80F92 Development Kit
User Manual
Introduction
UM013911-0607
6
Figure 2 is a photographic representation of the eZ80Acclaim!
®
Develop-
ment Platform segmented into its key blocks, as shown in the legend for
the figure.
Note: Key to blocks A–E.
A. Power and serial communications.
B. eZ80F92 Flash Module interface.
C. Debug interface.
D. Application module interfaces.
E. GPIO and LED with Address Decoder.
Figure 2. The eZ80Acclaim!
®
Development Platform
D
E
A
B
C
