Optional Features
Model SS Safety Light Curtain
- A - 4 -
MULTI-PYLON (MP)
Description:
Multiple sets of light curtains operating independently
can be modifi ed to operate together to prevent infrared
interference between each other, and optionally to
provide a single Dual Safety Output.
Wiring:
The Pink wire of each Receiver pylon must be connected
together as well as the White wires connected together.
Operation:
Standard= Each curtain uses its own Safety Outputs,
but do not interfere with each other.
Single Output: Blocking 1 curtain will shut down the
Safety Outputs of all connected light curtains.
Remote Status Display (RSD) Continued
The fi rst three numbers displayed represent the fi rst
problem beam on the guard starting from the cable end
of the pylon. The fourth number represents the total
number of beams blocked on the guard. Depending
if your beam spacing is 0.5” or 1.0” you can determine
which board in the pylon is bad.
Defi nitions
BEAM #: Indicates fi rst blocked beam (from cable
end). (i.e. 64 = 64” up with 1.0” beam
spacing, or 32” up with 0.5” spacing)
TOTAL #: Indicates total number of blocked beams
on the curtain.
(i.e., 1 to 9 beams then A to F = 10 to 15
beams)
The Diagnostics Display has two modes of operation:
Status and Fault. If a fault occurs, the display will scroll
the fault message until the power is removed.
Status Display Messages
Normal Operation
TEST Testing internal systems
RST Unit waiting for Push of FN1 (located on
control module power supply board middle
left hand side)
RDY Normal operation
Obstruction
03 > 15 or more beams blocked starting 3 beams
up from cable end
153 3 beams out starting 15 beams up from
cable end
Floating Blank
FB1 1 beam fl oat maximum
FB2 2 beams fl oat maximum
FB21 2 beams fl oat maximum, 1 beam is blocked
OBST More than 2 separate objects detected in
curtain
Auto Blank
AB3 3 beams programmed in as an Auto Blank
object
PENT Mode 1 penetration into guard
SIZE Total number of allowable blanked beams
exceeded during programming
MOVE Auto Blank object(s) moved, uncovering
beam(s)
Cincinnati Interface
CINN Guard has de-energized safety relays,
forcing a false blockage mode
Beam # Total#
