Jet-Light 2 x 18 W, FL-18
Operating instructions Stand: FL-06-2011_K
4 Overview of the device
Here is an overview of the operating parts and displays of the device and a short description of the
functions.
Item Description Item Description
1 Handle 8 Feet of the stand
2 Reflector 9 Stand
3 Screws on the protective cover 10 Foot screws (snap closing)
4 Lamp holder 11 Protective cover
5 Housing 12 Starter
6 Adjustable screws (snap closing) 13 Bulbs
7 Cable including plug 14 Distance piece
5 Technical data
Device Jet-Light 2 x 18 W, FL-18
Protective system: IP 44 (protected from splashes)
Electricity supply: 230 V~ 50 Hz
Cable: Rubber cable H07RN-F 2x1.0
Length:5 m
Power consumption: up to 36 W (2 x 18 W bulbs)
Bulbs: 2 x 18 Watt, PL-L fluorescent bulbs
(corresponds to light power of a light bulb
of approximately 200 W)
Base: 2G11
Protection class:
II
7
2
4
5
6
3
8
9
10
11
12
14
12
1
13
