Parr Instrument Series 4530 - Manual (Page 23)

Floor Stand Reactors
w w w . p a r r i n s t . c o m 23
OVERARM PARTS LIST
Motor
Part No. Description
A388E6 Air Motor
A388EES Motor 1/4 HP VS 90 VDC
A388E2ES Motor 1/2 HP VS 90VDC
A388EEQ Motor 1/4 HP EXP VS 90 VDC
A388E2ET Motor 1/2 HP VS 180 VDC
A388EER Motor 1/4 HP EXP VS 180 VDC
A388EET Motor 1/4 HP VS 180 VDC
Driven Pulley Assembly
Part No. Description
A2519HC Driven Pulley Assembly
706HC2 Pulley, Driven
725HC Support Hub
730HC Ball Bearing
731HC Snap Ring Internal 2”
732HC Snap Ring External 1”
2429HC Bushing PTFE
Upper Drive Shafts
Part No. Description Code
A742HC14 Upper Drive Shaft 9.82” (cart only) LD
A742HC7 Upper Drive Shaft 7.3” (cart only) HD
A2564HC
Upper Drive Shaft, 1/4 hp,
A1120HC
LD
A2564HC2
Upper Drive Shaft, 1/4 - 1/2 hp,
A1180HC
HD
Shaft Couplings
Part No. Description
A722HC Shaft Coupling Rubber (cart only)
2352HC Shaft Coupling .50, Universal
Release knobs
Part No. Description
726HC Release Knob, .50 Shaft
Drive Pulleys (Motor)
Part No. Description
695HC5 Pulley 600 RPM
695HC3 Pulley 1000 RPM
695HC2 Pulley 1700 RPM
Pulley Belt Combinations (HD Drive)
HD Pulley Cart-Belt FH-Belt
695HC5 728HC 728HC5
695HC3 728HC 728HC5
695HC2 728HC3 728HC6
Optional Tach Parts
Part No. Description
1564HC Optical Wheel
A1001E Tach Sensor Assembly (9.0”L)
