Floor Stand Reactors
P a r r I n s t r u m e n t C o m p a n y 16
PARTS LISTS
Reaction Vessel Parts List
Consult the itemized list for your reactor provided
along with this manual. For purpose of reactor iden-
tifi cation, the following abbreviation/codes are used:
FH - Fixed Head LD - Light Duty
RV - Removable Head HD - Heavy Duty
FG - Flat Gasket OS - O-Ring Seal
MD - Mag Drive FMD - Footless Mag Drive
* For parts made from alternate materials use the
codes shown below as a suffi x to the standard part
number.
CM - Alloy 400 CC - Alloy 20Cb3
CT - Alloy 600 CA - Titanium G2 or G4
CG - Alloy B-2 CH - Alloy C-276
CX - Zirconium
Cylinders
Part No. Description Code
236HC10 Cylinder, 1000 mL FG
236HC20 Cylinder, 2000 mL FG
2742HC10 Cylinder, 1000 mL OS
2742HC20 Cylinder, 2000 mL OS
Heads
Part No. Description Code
1370HC20 Head RVFG LD MD
1370HC25 Head RVFG LD FMD
755HC50 Head RVFG HD MD
755HC55 Head RVFG HD FMD
2252HC20 Head FHFG LD MD
2252HC25 Head FHFG LD FMD
2259HC20 Head FHFG HD MD
2259HC25 Head FHFG HD FMD
2740HC20 Head RVOS LD MD
2740HC25 Head RVOS LD FMD
2748HC20 Head FHOS LD MD
2748HC55 Head FHOS LD FMD
2750HC20 Head FHOS LD MD
2750HC25 Head FHOS LD FMD
2758HC20 Head FHOS HD MD
2758HC25 Head FHOS HD FMD
Internal Fittings
Dip Tubes
Part No. Description
257HC26 Dip Tube with nut, 1000 mL
257HC27 Dip Tube with nut, 2000 mL
Shafts
Part No. Description Code
352HC6 Stub Shaft, mag. drive RV LD
352HC9 Stub shaft, mag. drive FH LD
1025HC39 Upper Shaft FH HD
1025HC14 Upper Shaft RV HD
2141HC5 Shaft, 1000 mL FH LD FMD
2141HC6 Shaft, 2000 mL FH LD FMD
2141HC44 Shaft, 1000 mL MV LD FMD
2141HC45 Shaft, 2000 mL MV LD FMD
2135HC Shaft, 1000 mL FH HD FMD
2135HC2 Shaft, 2000 mL FH HD FMD
A449HC
Shaft assembly with coupling,
1000 mL
LD
A449HC2
Shaft assembly with coupling,
2000 mL
LD
A1030HC
Shaft assembly with coupling,
1000 mL
HD
A1030HC2
Shaft assembly with coupling,
2000 mL
HD
378HC Coupling, stirring shaft LD
379HC Pin, shaft, coupling LD
1028HC Coupling, stirrer shaft HD
1029HC Pin, shaft, coupling HD
447HC Shaft bushing, PTFE LD
1027HC Shaft, bushing, PTFE HD
448HC
Shaft with 447HC bushing,
1000 mL
LD
448HC2
Shaft with 447HC bushing,
2000 mL
LD
1025HC
Shaft with 1027HC bushing,
1000 mL
HD
1025HC2
Shaft with 1027HC bushing,
2000 mL
HD
A2148HC2
Impeller with set screws,
2.28” diameter
RV LD FMD
A2148HC3
Impeller with set screws, 2”
diameter
FH LD FMD
A2138HC4 Impeller, 2” diameter HD FMD
A358HC2
Impeller with set screws,
2.28” diameter
A358HC5
Impeller with set screws, 2”
diameter
358HC2F Set screws for impeller
Stirrer Support Brackets
Part No. Description Code
A380HC Stirrer Support Bracket FG
A1404HC Stirrer Support Bracket OS
