Settings:
•
Controlled by two (2) sixteen (16) position switches (as labeled on page 3 and on the module itself).
o One switch is for selecting the Function. The following functions (modes) exist at this time:
o The first switch setting in each PPM group (setting 0, 4, 8 or C) enables the gear change
simulation function (Table A).
o The second switch setting in each PPM group (setting 1, 5, 9, or D) enables the low speed
range (Table B, Low (1)) MPH activated switch function.
o The third switch setting in each PPM group (setting 2, 6, A or E) enables the standard speed
range (Table B, Std (2)) MPH output switch function.
o The fourth switch setting in each PPM group (setting 3, 7, B or F) enables the high speed
range (Table B, High (3)) MPH output switch function.
o Second switch is for selecting the Range (within table A or B)
Notes:
•
Changes to the MPH switch point settings must be done with the STOV powered off.
o The switch positions are only read on start up
Table A
Speed (MPH)
Gear Change
1
2
3
4
5
Range Switch Position
0
0
30
60
110 140 175
1
1
25
50
95
125 155
2
2
20
45
90
115 140
3
3
20
40
80
105 130
4
4
40
75
120 175 220
5
5
35
70
115 170 210
6
6
30
65
105 150 200
7
7
55
80
110 140 190
8
8
50
75
100 130 175
9
9
45
70
95
125 165
10
A
40
65
90
120 160
11
B
47
80
123 164 200
12
C
44
75
116 154 190
13
D
38
65
100 133 180
14
E
35
60
92
122 166
15
F
32
55
85
113 152
Table B
Switch Position
Speed in MPH (mode)
Low (1) Std (2) High (3)
Range Switch Position
0
OFF
OFF
OFF
1
1
10
110
2
2
20
120
3
3
30
130
4
4
40
140
5
5
50
150
6
6
60
160
7
7
70
170
8
8
80
180
9
9
90
190
A
10
100
200
B
11
110
210
C
12
120
220
D
13
130
230
E
14
140
240
F
15
150
250
