Fremont (MAXREFDES6#) Nexys 3 Quick Start Guide
6
4. Procedure
1. Connect the Fremont board to the JB1 port of a Nexys 3 development kit as
. Power up the Nexys 3 development kit.
2. Connect the +7V power supply to the EXT_V+ connector. Connect the -6V power
supply to the EXT_V- connector. Connect the ground terminal of the power
supplies to the GND2 connector.
3. Download the latest RD6V01_00.ZIP
file located at
All files available for download are
available at the bottom of the page.
4. Extract the RD6V01_00.ZIP file to a directory on your PC. The location is
arbitrary but the path prior to where you extract the .ZIP file must not exceed 82
characters due to the Windows 250-character total path limitation. For example,
this 90-character preceding path would be an example of a path that would be
too long:
C:\0123456789\0123456789\0123456789\0123456789\0123456789\0123456789\
0123456789\0123456789\0123456789\RD6V01_00.ZIP
(This path is too long.)
In addition, the Xilinx tools require the path to not contain any spaces.
C:\Do Not Use Spaces In The Path\RD6V01_00.ZIP
(This path has spaces.)
For the purposes of this document, it will be C:\designs\maxim\RD6V01_00\.
See
Appendix A: Project Structure and Key Filenames
the project structure and key filenames.
