71M6533- DB Demo Board User’s Manual
Page: 75 of 75 REV 3
5 REVISION HISTORY
Revision Date Description
1.0 1-30-2008 Initial release
1.1 2-5-2008
Updated copyright date in footers. Added text stating that no jumper should
be across VBAT and OPT_TX_OUT (J12) and updated Figure 3-1.
Updated pin description tables. Corrected Figure 2-9, added load line
graph for differential mode.
1.2 2-25-2008
Updated to include Demo Board revision DB6533T14A3 and new pin-out
arrangement of 71M6533.
Updated Calibration Procedures section.
2.0 6-13-2011
Replaced Teridian logo with Maxim logo in headers. Removed list of
Application Notes from section 2.6.
Added information on the USB-to-Serial Adapter.
2.1 9-26-2011
Corrected calculation and address for WRATE on page 23.
Intermediate revision (not published).
3 7-31-2012
Removed references to TGP1 Gang Programmer (no longer supported)
and to Debug Board (replaced by USB-Serial Adapter).
Changed naming conventions (71M6533-DB). Corrected name for TFP2.
Removed references to 71M6533H (the 71M6533-DB is shipped with the
71M6533).
Updated Figure 2-9.
Added comments on the use of ferrites and reference to Application Note
AN-5292 (2.4.7).
Added Battery-Mode Commands in section 1.8.1.
