14 Bit 46 Descriptor E 30 Bit 62 Descriptor E
15 Bit 47 Descriptor E 31 Bit 63 Descriptor E
16 Bit 48 Descriptor E 32 Bit 64 Descriptor E
LOCATION 61 – WIEGAND FORMAT 2 (PARITY TYPE 1) 0=No Parity; 1=Odd Parity; 2=Even Parity
1 Parity Type 1 0
LOCATION 62 – WIEGAND FORMAT 2 (PARITY MASK 1)
1 Parity Mask 1 -------- 5 Parity Mask 5 --------
2 Parity Mask 2 -------- 6 Parity Mask 6 --------
3 Parity Mask 3 -------- 7 Parity Mask 7 --------
4 Parity Mask 4 -------- 8 Parity Mask 8 --------
LOCATION 63 – WIEGAND FORMAT 2 (PARITY TYPE 2) 0=No Parity; 1=Odd Parity; 2=Even Parity
1 Parity Type 2 0
LOCATION 64 – WIEGAND FORMAT 2 (PARITY MASK 2)
1 Parity Mask 1 -------- 5 Parity Mask 5 --------
2 Parity Mask 2 -------- 6 Parity Mask 6 --------
3 Parity Mask 3 -------- 7 Parity Mask 7 --------
4 Parity Mask 4 -------- 8 Parity Mask 8 --------
LOCATION 65 – WIEGAND FORMAT 2 (PARITY TYPE 3) 0=No Parity; 1=Odd Parity; 2=Even Parity
1 Parity Type 3 0
LOCATION 66 – WIEGAND FORMAT 2 (PARITY MASK 3)
1 Parity Mask 1 -------- 5 Parity Mask 5 --------
2 Parity Mask 2 -------- 6 Parity Mask 6 --------
3 Parity Mask 3 -------- 7 Parity Mask 7 --------
4 Parity Mask 4 -------- 8 Parity Mask 8 --------
LOCATION 67 – WIEGAND FORMAT 2 (PARITY TYPE 4)
1 Parity Type 4 0
LOCATION 68 – WIEGAND FORMAT 2 (PARITY MASK 4)
1 Parity Mask 1 -------- 5 Parity Mask 5 --------
2 Parity Mask 2 -------- 6 Parity Mask 6 --------
3 Parity Mask 3 -------- 7 Parity Mask 7 --------
4 Parity Mask 4 -------- 8 Parity Mask 8 --------
LOCATION 69 – WIEGAND FORMAT 2 (PARITY TYPE 5)
1 Parity Type 5 0
LOCATION 70 – WIEGAND FORMAT 2 (PARITY MASK 5)
1 Parity Mask 1 -------- 5 Parity Mask 5 --------
2 Parity Mask 2 -------- 6 Parity Mask 6 --------
3 Parity Mask 3 -------- 7 Parity Mask 7 --------
4 Parity Mask 4 -------- 8 Parity Mask 8 --------
WEIGAND FORMAT 3
LOCATION 71 – WIEGAND FORMAT 3 (DIGITS & BITS) (DECIMAL DATA)
DESCRIPTION DEFAULT DATA
1 Number of Digits in Facility Code 4
2 Number of Digits in Badge Number 7
3 Number of Bits in Facility Code 12
4 Number of Bits in Badge Number 20
5 Total Number of Bits in Complete Weigand Format (including parity bits) 35
LOCATION 72 – WIEGAND FORMAT 3 (BIT DESCRIPTOR 1 - 32) HEX DATA
0 = Always Zero; 1 = Always One; B = Badge Number Bit; D = Parity Bit; E = End of Format; F = Facility Code Bit
SEG DESCRIPTION DEFAULT DATA SEG DESCRIPTION DEFAULT DATA
1 Bit 1 Descriptor D 17 Bit 17 Descriptor B
2 Bit 2 Descriptor D 18 Bit 18 Descriptor B
3 Bit 3 Descriptor F 19 Bit 19 Descriptor B
4 Bit 4 Descriptor F 20 Bit 20 Descriptor B
5 Bit 5 Descriptor F 21 Bit 21 Descriptor B
6 Bit 6 Descriptor F 22 Bit 22 Descriptor B
7 Bit 7 Descriptor F 23 Bit 23 Descriptor B
8 Bit 8 Descriptor F 24 Bit 24 Descriptor B
9 Bit 9 Descriptor F 25 Bit 25 Descriptor B
10 Bit 10 Descriptor F 26 Bit 26 Descriptor B
11 Bit 11 Descriptor F 27 Bit 27 Descriptor B
12 Bit 12 Descriptor F 28 Bit 28 Descriptor B
13 Bit 13 Descriptor F 29 Bit 29 Descriptor B
14 Bit 14 Descriptor F 30 Bit 30 Descriptor B
15 Bit 15 Descriptor B 31 Bit 31 Descriptor B
16 Bit 16 Descriptor B 32 Bit 32 Descriptor B
LOCATION 73 – WIEGAND FORMAT 3 (BIT DESCRIPTOR 33 - 64)
SEG DESCRIPTION DEFAULT DATA SEG DESCRIPTION DEFAULT DATA
1 Bit 33 Descriptor B 17 Bit 49 Descriptor E
2 Bit 34 Descriptor B 18 Bit 50 Descriptor E
3 Bit 35 Descriptor D 19 Bit 51 Descriptor E
4 Bit 36 Descriptor E 20 Bit 52 Descriptor E
5 Bit 37 Descriptor E 21 Bit 53 Descriptor E
6 Bit 38 Descriptor E 22 Bit 54 Descriptor E
7 Bit 39 Descriptor E 23 Bit 55 Descriptor E
8 Bit 40 Descriptor E 24 Bit 56 Descriptor E
9 Bit 41 Descriptor E 25 Bit 57 Descriptor E
10 Bit 42 Descriptor E 26 Bit 58 Descriptor E
11 Bit 43 Descriptor E 27 Bit 59 Descriptor E
12 Bit 44 Descriptor E 28 Bit 60 Descriptor E
13 Bit 45 Descriptor E 29 Bit 61 Descriptor E
14 Bit 46 Descriptor E 30 Bit 62 Descriptor E
15 Bit 47 Descriptor E 31 Bit 63 Descriptor E
16 Bit 48 Descriptor E 32 Bit 64 Descriptor E
LOCATION 74 – WIEGAND FORMAT 3 (PARITY TYPE 1) 0=No Parity; 1=Odd Parity; 2=Even Parity
1 Parity Type 1 1
LOCATION 75 – WIEGAND FORMAT 3 (PARITY MASK 1)
1 Parity Mask 1 12345678 5 Parity Mask 5 -----678
2 Parity Mask 2 12345678 6 Parity Mask 6 --------
