3BChapter 4: Basic setup
TruVision Mini PTZ 12X Camera User Manual 33
Figure 18: Shadow Tour menu
Table 15: Shadow Tour menu description
Function Description
Shadow Tour Up to eight shadow tours can be defined. Using LEFT/RIGHT direction
keys to select a shadow tour number first and then follow the steps
below to start recording the Shadow Tour path.
Record Start You need to define where the shadow tour starts.
Record End You need to define where the shadow tour ends.
Run Shadow Tour When the shadow tour is recorded, select this option to playback the
Shadow Tour.
Exit Select Yes to save any changes and return to Main Page 2.
To record a “quick” shadow tour (shadow tour #1)
1. Rotate the dome camera to the desired view and setup the tilt and zoom start
position. Using a KTD-405 keypad, hold the esc key and press tour. Then press
zoom +.
Note: You must be in normal operation mode when carrying out this function. It
cannot be done from programming mode.
2. Press esc to exit and save Shadow Tour #1.
To record a shadow tour
1. In the Shadow Tour menu, select the number of the shadow tour being recorded.
2. Select Record Start and press set (ENTER). Move to the desired start position.
3. Press set (ENTER) to start recording the shadow tour using the joystick or keypad
to create the shadow tour path.
4. Press set (ENTER) once to save the shadow tour. The cursor moves automatically
to Record End.
Note: When the Record Start is saved, a message will automatically appear on-
screen to show how much of the buffer memory remains. Once the buffer
percentage reaches 100%, the path will not be recorded.
5. Select Run S. Tour to replay the saved tour.
6. When you are happy with the shadow tour recorded, exit the menu and return to
the main menu.
