-22-

I : \ O F F I C E \ W P M A N U A L \ M a n 2 0 0 r v b . w p d

Record voltages in Table IV (last column) before contacting the factory. Be sure to use a high input
impedance digital voltmeter for the readings identified in Table IV. All readings are to be taken from
terminals BRN through R on JP2 (Figure 2) with power on and a typical flow rate flowing through the
sensor. Complete Table IV and fax it to the factory (614-895-0319).

TABLE IV. Field Check Readings

JP4WIRE

LABEL†

TRANSDUCER CABLE / WIRE

SIGNAL DEFINITION

EXPECTED

VOLTAGE [Vdc]

RECORDED

VOLTAGE

[Vdc]

BRN

Flow sensor common voltage sense

Range: !5 to

!50mV

BLU

BRN

Flow sensor heated RTD voltage sense

Range: .2 to .4V

BRN

Flow sensor heated RTD current source

Range: .2 to .4V

BRN

Flow sensor reference RTD voltage sense

Range: .2 to .4V

BLK

BRN

Flow sensor reference RTD current source

Range: .2 to .4V

BRN

Flow sensor heater

<10V

† Connect + lead of volt meter to + column; Connect ! lead of volt meter to ! column.
