13
II. USER-SELECTABLE SWITCH
The
FAX-60
offers a number of user-selectable functions via the User Selectable Switches
which are initially programmed as
00000001
by the factory. Each of these digits is a "switch"
that controls a specific parameter of the facsimile machine.
Plaits
Parameters they control
Digit 1:
Digit 2:
Digits 3 and 4:
Digit 5:
Digit 6;
Digit 7:
Digit 8;
The transmission speed
The presence or absence of audible tone
The resolution mode - NORMAL, FINE, PHOTO
The OGM recording mode
The presence or absence of end-of-page mark
NOT USED
The MEMO recording mode
The following table summarizes the digits, the items they control, the factory settings, the
optional settings and the new codes for the optional settings.
Digit No.
Item controlled
Factory Set & Code
Optional Setting & Code
1
G3 transmission speed
4800 bps (0)
2400 bps (1)
2
Audible tone
Present (0)
Absent (1)
3 & 4
Resolution mode
NORMAL (00)
FINE (10)
5
OGM recording mode
Enhanced (0)
PHOTO (grey scale) (11)
Standard (1)
6
End-of-page mark
Present (0)
Absent (1)
7
8
NOT USED
MEMO recording mode
Standard (1)
Enhanced (0)
For example, when the factory selected for digits 3 and 4 the setting of
00,
the
FAX-60
will
automatically select the NORMAL mode as the "home position". However, if most of your
transmissions are of photographs, you may wish to change the "home position" to PHOTO (by
setting the digits 3 and 4 to 11. See below for the procedure.
To set a user-selectable function:
1.
Turn the power OFF.
"CAUTION:
BOTH ICM AND OGM MESSAGES WILL BE ERASED IN THE EVENT
OF A POWER INTERRUPTION. CARE SHOULD BE EXERCISED WHEN
UNPLUGGING THE UNIT OR TURNING OFF THE UNIT'S MAIN POWER SWITCH."
2.
Turn the power ON again while depressing the
FINE/PHOTO
button.
3.
The unit will automatically print out;
****************Qypp^l^j jjg^p SWITCH SETTING*“**************
*
*
*
USER SWITCHES:
00000001
*
*
**************************PyQ^^_0Q****************************
The
FINE lamp will
blink.
4.
Select the digit you wish to change and press the
FINE/PHOTO
button the appropriate
number of times. For example, to select digit 2, press
FINE/PHOTO
button twice.
