VOLUME
BASS/TREBLE
VIBRATION
0 3 2 1
INPUT
OUTPUT
Step 1: Plug one end of the wireless audio cord (10) into
the audio INPUT (D) of BoomChair™.
Step 2: Plug the other end of the wireless audio cord (10)
into the headphone jack of your device.
Step 3: Turn Boomchair™ on by turning Power/Volume
knob (A) clockwise.
Step 4: Turn portable device on.
iPod
MP Player
Portable Audio Device
PSP
Nintendo DS
Portable Game
CONNECTING TO PORTABLE AUDIO / VIDEO DEVICES
WIRElESS CONNECTION
WIRElESS CONNECTION
3a
AUDIO
OUT
iPod
MP Player
Portable Audio Device
PSP
Nintendo DS
Portable Game
10
CONNECTING TO AUDIO / VIDEO DEVICES
Step 1: Insert 4 AA batteries (not included) into wireless
transmitter. Turn power switch on.
Step 2: Plug one end of the wireless audio cord (10) into
the wireless transmitter.
Step 3: Plug the other end of the wireless audio cord (10)
into the headphone jack of your device.
Step 4: Turn Boomchair™ on by turning Power/Volume
knob (A) clockwise.
Step 5: Set transmitter and Boomchair™ channel switch
(E) to matching frequency.
Step 1: Plug the mini audio end of RCA cord (3a)
into audio INPUT (D) of BoomChair™.
Step 2: Plug the red/white ends of RCA cord (3a)
into AUDIO OUTPUT of Audio/Video device.
Step 3: Turn Boomchair™ on by turning Power/
Volume knob (A) clockwise.
Step 4: Turn Audio/Video device on.
3a
AUDIO
OUT
Step 1: Insert 4 AA batteries (not included) into
wireless transmitter. Turn power switch on.
Step 2: Plug mini audio end of RCA cord (3a)
into the wireless transmitter.
Step 3: Plug red/white ends of RCA cord (3a)
into AUDIO OUTPUT of Audio/Video device.
Step 4: Turn Boomchair™ on by turning Power/
Volume knob (A) clockwise.
Step 5: Set transmitter and Boomchair™ channel
switch (E) to matching frequency.
TV
VCR
DVD
Stereo
Satellite Receiver
Other Devices
TV
VCR
DVD
Stereo
Satellite Receiver
Other Devices
DIRECT CONNECTION - BE SURE THE WIRElESS CHANNEl SElECTOR IS SWITCHED TO “0”
BE SURE THE WIRElESS CHANNEl SElECTOR NUMBER ON THE CHAIR MATCHES THE
TRANSMITTER WITH CORRESpONDING NUMBER OF DOTS
DIRECT CONNECTION - BE SURE THE WIRElESS CHANNEl SElECTOR IS SWITCHED TO “0”
BE SURE THE WIRElESS CHANNEl SElECTOR NUMBER ON THE CHAIR MATCHES THE
TRANSMITTER WITH CORRESpONDING NUMBER OF DOTS
VOLUME
BASS/TREBLE
VIBRATION
0 3 2 1
INPUT
OUTPUT
10
