AquaCraft VS1 - Manual (Page 19)

Stock # Description Type Diameter Pitch Bore Octura Equivalent Prather Equivalent
AQUB9715 40 x 53 2-Blade 40mm 53mm 3/16" 440 215
AQUB9720 40 x 52/3 3-Blade 40mm 52mm 3/16" 440 220
™
Precision cast from Copper-Beryllium-Titanium! Precision cast from Copper-Beryllium-Titanium!
Give your VS1 an added burst of speed — as easily as bolting on a high-quality copper-beryllium-titanium GrimRacer metal
prop! Racer-designed and USA-made, these are the most accurately cast metal props available. Ultra-clean casting and true
center-bore hubs place each prop near its balance point right out of the package. You can fi ne-tune them using less effort
than stainless steel props require — and they hold their shape better for balancing, sharpening, and changing pitch.
19
ENGINE MOUNT TEMPLATE
Cut Line
Drill four 5/32" holes
for motor mount bolts Drill one 3/32" hole for
ON/OFF switch wire
Switch
Hole
