3. Using GrimRacer speed grease, apply a small amount to
the shaft and slide the shaft back into the boat. Be careful to
align the drive shaft to the hole in the end of the motor coupler
and align the fl at spot in the shaft with the set screw. Tighten the
set screw holding the drive shaft in place. Do not overtighten.
4. Now is also a good time to place a drop of light oil on the
motor bearing.
Linking Transmitter and Receiver
Linking: Your Tactic transmitter and receiver come pre-linked
from the factory. If for any reason this is interrupted or you
need to replace either the transmitter or receiver you will have
to re-link the two together.
To link the Tx and Rx:
1. Turn on the transmitter.
2. Apply power to the receiver
3. If the receiver’s LED fl ashes once and then stays on, the Rx
is already linked to the Tx and you can skip to the next section.
Otherwise, push and hold the receiver’s “BIND” button until
its LED glows red and then turns off after about one second.
4. Release the BIND button.
5. If the linking is successful, the LED will fl ash once and
then remain ON.
6. Test for proper Tx/Rx functionality by completing the next
section. If it doesn’t seem the radio has linked properly, repeat
steps 1-6 above.
One more thing we would like to point out about your P-27
Gunslinger Crackerbox. The prop shaft is offset on the bottom
of your hull. It looks crooked, and it is offset, but this is done
intentionally as it helps control torque from the prop and motor.
Ordering Replacement Parts
To order replacement parts for the AquaCraft P-27 Gunslinger,
use the order numbers in the replacement parts list.
Replacement parts can be purchased from your local hobby
shop or by mail order. If you need assistance locating a dealer
to purchase parts, visit www.aquacraftmodels.com and click
on “Where to buy”. If you are missing parts, contact Hobbico
Product Support at:
Phone: 217.398.8970
Fax: 217.398.7721
E-mail: [email protected]
Parts List
AQUB6241 Cowl
AQUB6251 Prop
Shaft
AQUB6332 Decal Sheet
AQUB6402 Cowl Latch
AQUB7766 535 Injection Molded Prop
AQUB7852 Drive dog with prop nut
AQUB7854 Motor Coupler with set screws
AQUB7916 Motor Mount
AQUB8617 Radio box lid
AQUB8767 Rudder linkage
AQUB8768 Rudder Blade
AQUB8769 Rudder Support Bracket with Hinge Pin
AQUB8770 Rudder Bracket with Steering Arm
AQUB8782 Servo Mount
AQUB9015 Skid Fin
AQUB9041 Trim Plates (2)
AQUB9500 Grimracer Speed Grease
AQUB9503 Radio box rubber seal boots
AQUB9506 Transom drain plug
AQUB9514 Grimracer Pro Radio Box Tape
AQUB9548 28mm CNC water jacket with O-rings
AQUB9700 Metal Prop 36x55 2-Blade
AQUG7010 28-56-1800kV 6 pole In-runner motor
AQUM7000 50-Amp Water Cooled Motor Controller
DTXP4235 LiPo Charger Onyx 235
GPMM3318 AC/DC 3S LiPo Balancing Smart Charger
GPMP0861
ElectriFly LiPo 3S 11.1V 2200mAh 30C
GPMP0871 ElectriFly LiPo 3S 11.1V 3200mAh 25C
TACJ0245 Tactic Pistol Grip Radio System
TACL0324 Tactic 2.4GHz Receiver Only
TACM0235 Tactic TSX35 Standard Sport Servo
