Safety Precautions
● Never, ever attempt to swim after a stalled RC boat.
Do not get in the water for any reason to retrieve your
boat. To aid you in retrieving a stalled RC boat set up
a fi shing reel with a tennis ball tied to the end of the
line. Or better yet get yourself a small Jon boat so you
can row out and pick up your boat. Remember to use
a PFD any time you enter your retrieval craft.
● AquaCraft products are to be used by ages 14 and over.
● Do not touch the propeller anytime the motor is running.
Pay equally close attention to items such as loose clothing,
shirt sleeves, ties, scarves, long hair or anything that may
become entangled in the spinning prop. If your fi ngers,
hands, etc. come in contact with the spinning propeller, you
may be severely injured.
● The speed and mass of this boat can infl ict property damage
and severe personal injury if a collision occurs. Never run this
boat in the presence of swimmers or where the possibility
of collision with people or property exists.
● Electric motors produce heat. Do not touch any part of your
motor until it has cooled.
● This boat is controlled by radio signals, which are susceptible
to possible interference from other R/C transmitters, paging
systems, or other electrical noise.
● In the event that weeds become entangled in the propeller,
stop the motor before attempting to remove them.
● Rough water and high winds can make your boat fl ip easily
and make it diffi cult to control. Operating in rough water or
high winds should be avoided.
● If your boat should happen to stall, water currents will slowly
carry it to shore. Keep in mind that the boat could be carried
to the opposite shore. When surveying areas to run your
boat, keep variables in mind such as wind direction, size
of the lake, etc. It is not advisable to run R/C boats on any
free-fl owing bodies of water such as creeks or rivers.
● Always remove the battery pack from the boat before
charging.
Specifi cations
P-27 GUNSLINGER BOAT:
Hull Length: 28" (711mm)
Overall Length: 29.5" (750mm)
Height: 6" (152mm)
Width: 10.25" (267mm)
Weight (Less Battery): 37.5oz (106.5g)
Motor: Brushless, 28mm x 56mm,
6 pole, 1800KV, inrunner
Battery Type Required: 3S LiPo
Motor Controller: 50 amp
Input Voltage: 3S-11.1V
Ba ttery Mounting
Area Dimensions: 6.25" x 2.5" x 1.5"
Speed: 20mph
Run time:
8 minutes approx.
(3200mAh battery)
BOAT FEATURES:
● Tactic TTX240 2.4GHz transmitter with TR325 receiver
● 1800kV brushless in runner motor
● LiPo ready (3S) 50 Amp brushless motor controller with
low battery stutter warning system and battery cut off
circuit.
● Tough, lightweight ABS construction with square hatch
opening for easy taping
● Great looking pre-applied Gunslinger graphics
● Rudder with kick back design
● Separate water proof radio box for the receiver and
steering servo
ALSO INCLUDES:
● Scale subsurface drive propeller system
● Water cooled motor
● Water cooled motor controller
● Transom mounted water pickup
● 1/8" [3.2mm] prop shaft
● Two blade FRP propeller
● Transom drain plug
● Performance offset driveline
MOTOR:
KV Rating: 1800kV
Rated Operational Voltage: 7-25V
(2-6s)
Operating Current (no load): 1.7A, 8V/DC
Max Current: 70A
Loaded Optimum Working Range: 45A-50A
Shaft Diameter: 3.175mm
Motor Resistance: 55
m

Dimension: 28x56mm
Weight: 135g
MOTOR CONTROLLER:
Amps: 50amp continuous
Max Amps: 65A 10 sec
Voltage Range: 9V-12.6V
BEC: 5V 2A
Motor Connectors: 4mm bullet (3)
Battery Connector: Deans
Stutter Voltage: 9.7
volts
LVC: 9 volts
Wire Gauge: #14
Max Output Power: 500 watts
On-Resistance: 0.0015 ohms
Operating Frequency: 8KHZ PWM , 16MHZ
MCU
Timing Angle: Auto
