3
FEATURES & SPECIFICATIONS
MINIMONO BOAT SPECIFICATIONS:
Hull Length: 16" [407mm]
Overall Length: 18” [458mm]
Width: 5.5" [140mm]
Height: 3.25” [83mm]
Weight: 10oz (28.5g) less battery
Run times: 4 to 6 minutes
Speeds: Up to 25mph
BOAT FEATURES:
➧ Tactic TTX240 2.4GHz transmitter with TR325 receiver
➧ 2200kV brushless outrunner motor
➧ LiPo ready (3S) 20 Amp brushless motor controller with low
battery warning system and battery cut off circuit
➧ Tough, lightweight ABS construction with square hatch opening
for easy taping
➧ Great looking, pre-applied graphics
Other standard features include:
➧ Surface drive propeller system
➧ Water cooled motor mount
➧ Music-wire drive shaft
➧ Break-away wedge rudder
➧ One piece aluminum fin-plates
➧ Transom mounted water pickup
➧ 1/8" [3.2mm] prop shaft
➧ Two blade 30mm FRP propeller
➧ Transom drain plug
MOTOR SPECIFICATIONS:
KV Rating: 2200kV
Operate Current: 1.4A, 8V/DC (without loading)
Input: 3-S LiPo Battery
Max Current: 28A/15S
Shaft Diameter: 3.175mm
Motor Resistance: 50 m

Dimension: 27.5 x 30mm
Weight: 47g
MOTOR CONTROLLER:
Rated current: 20amp
Battery Connectors: Male Deans
® Ultra Plug ®
Motor Connectors: 3.5mm gold plated bullet connectors
Wire Gauge: 14G
Stutter Bump Warning System: 9.6V
Low Voltage Cutoff: 9V
BEC Max Current: 2A
PWM: 8K
Dimensionx: 45mm x 24mm x 9mm
E-mail: [email protected] y
SAFETY PRECAUTIONS
➧ Never, ever, attempt to swim after a stalled RC boat. DO NOT get
in the water for any reason to retrieve your boat. Your Minimono
has flotation added to the interior of the hull. It will not sink. To
aid you in retrieving a stalled RC boat you can use a fishing reel
with a tennis ball tied to the end of the line. Or better yet, get
yourself a small Jon boat so you can row out and pick up your
boat. Remember to use a personal flotation device any time you
enter your retrieval craft.
➧ AquaCraft products are to be used by ages 14 and over.
➧ Do not touch the propeller anytime the motor is running. Pay equally
close attention to items such as loose clothing, shirtsleeves, ties,
scarves, long hair or anything that may become entangled in the
spinning prop. If your fingers, hands, etc. come in contact with the
spinning propeller, you may be severely injured.
➧ The speed and mass of this boat can inflict property damage and
severe personal injury if a collision occurs. Never run this boat
in the presence of swimmers or where the possibility of collision
with people or property exists.
➧ Electric motors produce heat. Do not touch any part of your motor
until it has cooled.
➧ This boat is controlled by radio signals, which are susceptible
to possible interference from other R/C transmitters, paging
systems, or other electrical noise.
➧ In the event that weeds become entangled in the propeller, stop the
motor before attempting to remove them.
➧ If your boat should happen to stall, water currents will slowly
carry it to shore. Keep in mind that the boat could be carried to
the opposite shore. When surveying areas to run your Minimono,
keep variables in mind such as wind direction, size of the lake, etc.
It is not advisable to run R/C boats on any free-flowing bodies of
water such as creeks or rivers.
➧ Always remove the battery pack from the boat before charging.
