© Inovonics, 2011 - www.inovonics.com 4
Note: The test mode will automatically terminate after 30 minutes of inactivity.
Factory Config
The F ACTORY C ONFIG option is used to restore the EE4232MR to its factory defaults.
Caution: Choosing F ACTORY C ONFIG will erase all programmed point and output
information, as well as passwords and the LED password protect settings.
To restore the factory configuration defaults to the EE4232MR:
1.
From the I NSTALL & S ERVICE menu, use the Up and Down buttons to navigate to
the F ACTORY C ONFIG prompt; press the Enter button.
2. The R ESET C ONFIG prompt displays. Use the Up and Down buttons to choose Y
for yes; press Enter to select.
3. The C ONFIG R ESET prompt displays; press the Enter button to return to the
I NSTALL & S ERVICE menu.
The receiver can also be brought back to the factory default configuration through a
hardware initiated sequence.
1.
Connect a wire between the reset terminal and the ground terminal
2. While pressing the Back button, cycle the power to the unit
3. Release the Back button and remove the wire between the reset terminal and
ground
4. R ESET C ONFIG ? displays; select Y and press the Enter button
Select Language
1. At the S ELECT L ANGUAGE prompt, press Enter.
2. Use the Up/Down buttons to scroll through the language options. The C LEAR
L ANG option resets the language to the default and exits the I NSTALL & S ERVICE
menu.
3. Press Enter to select language.
4. When L ANGUAGE S ELECTED displays, press Enter to return to the I NSTALL &
S ERVICE menu.
To reset the language selection:
1.
Press the Up and Enter keys while cycling the power.
2. The S ELECT L ANGUAGE prompt displays. Follow the steps above to choose a new
language.
Change Password
Caution: CENELEC Grade 2 applications must have a password of at least four
digits.
Passwords can be up to eight digits long. The default authorized user password is
1234; the default authorized installer password is 3446. To change the password:
1.
From the I NSTALL & S ERVICE menu, press Enter at the C HANGE P ASSWORD
prompt.
2. Use the Up/Down buttons to choose either U SER P ASSWORD or I NSTALL
P ASSWORD ; press Enter to select.
3. Use the Up/Down buttons to scroll through the digits; press Enter to select and
advance to the next digit.
Note: Choosing a null as the password will disable the function, allowing users to
perform receiver functions and/or change parameters without a password.
4. When finished, press Enter again to complete selection.
5. When P ASSWORD C HANGED displays, press Enter to return to the I NSTALL &
S ERVICE menu.
Caution: Store the new password in a secure place. If the new password is lost, you
will not be able to access the receiver without restoring it to factory defaults as
described in section , “Factory Config” on page 4.
Signal Strength
The S IGNAL S TRENGTH option is used to measure signal strength and troubleshoot
installation problems.
1.
At the S IGNAL S TRENGTH prompt, press Enter.
• The first programmed point displays, along with a signal quality of G OOD , W EAK
or N O S IG .
Note: The point must have an active transmitter associated with it to display signal
strength.
2. Use the Up/Down buttons to scroll through the registered transmitters.
3. Press Enter to view Level (LV) and Margin (MA).
• LV indicates the overall signal strength; MA indicates the signal strength minus
the background noise.
Note: Inovonics recommends an LV of four for most installations. For CENELEC,
Grade 2 installations, an LV of 10 or greater is required.
Delete Point
The D ELETE P OINT option allows you to delete transmitter registration information from
all registered points, or from a specific point. Programmed point information is not
deleted; just the registration identification number associated with the transmitters or
repeaters. To delete points:
1.
From the I NSTALL & S ERVICE menu, use the Up and Down buttons to navigate to
the D ELETE P OINT prompt; press the Enter button.
2. The D ELETE A LL ? prompt displays. Use the Up and Down buttons to choose N for
no or Y for yes; press Enter to select.
3. If you selected no, the D ELETE P OINT prompt displays. Use the Up and Down
buttons to choose a point to delete; press Enter to select.
4. Press the Enter button. If there is more than one registered point, then pressing
the Enter button returns to point selection for deletion; if there are no more
registered points, the display returns to the I
NSTALL & S ERVICE menu.
Register Transmitter
The R EGISTER X MITTER option allows you to register a transmitter or repeater.
1. From the I NSTALL & S ERVICE menu, use the Up and Down buttons to navigate to
the R EGISTER X MITTER prompt; press the Enter button.
2. Use the Up and Down buttons to choose the point to which you want to register
the transmitter/repeater.
3. Use the Up and Down buttons to toggle between N for no and Y for yes to choose
whether or not you wish to register a transmitter/repeater to the point; press Enter
to select.
4. Press the transmitter/repeater’s Reset button at the R ESET X MITTER prompt.
10.3 Event Log
The event log displays the last 50 events that have occurred, whether they be alarms
or tamper, inactive, or low battery faults. Event log information is available without a
password.
1.
From system status information, press Enter.
2. Use the Up or Down buttons to navigate to E VENT L OG ; press the Enter button.
3. Use the Up/Down buttons to scroll through events.
4. When viewing transmitter events, press Enter to see the output the events map
to.
Note: No output will be displayed if the event is mapped to a null output.
11 Specifications
Dimensions: 22cm x 18cm x 4cm (8.75" x 7" x 1.63" ).
Weight: 522 g (18.4 oz)
Operating environment: -10°- 60°C (14°- 140°F), 90% relative humidity, non-
condensing.
Power requirement: 11-14 VDC; 500mA
Nominal current consumption: Approx. 120 mA
Output specifications: Form C relay 1A @ 28 VDC, 0.5 @ 30 VAC resistive load
Input specifications: Reset input: Contact closure, momentary low.
Receiver type: Frequency hopping spread spectrum.
Operating frequency: 868-869 MHz
Tamper: Type B, fixed device.
Number of points/Transmitters: 32.
Number of outputs: 12 Form C relay outputs
Event history log capacity: 50 events (first-in, first-out replacement).
11.1 Means of Conformity
Inovonics Wireless Corporation declares that the product listed above is in conformity
with the essential requirements and provisions of the following Council Directives:
• R&TTE Directive 1999/5/EC
• Low Voltage Directive 2006/95/EC
• EMC Directive 2004/108/EC
and conforms to the following standards:
• EN 300 220-1: 2006 Receiver Class 1, Temperature Category 1
• EN 301 489-1 V1.8.1: 2008
• EN 60950-1: 2006
• EN 50130-4: 1995 + A1:1998 + A2:2003
• EN 50130-5: 1998
• EN 50131-1: 2006 Security Grade 2, Environmental Class II
• EN 50131-3: 2008
• EN 50131-5-3: 2005
Product certified by Telefication B.V.
12 Warranty/Disclaimer
Caution: Changes or modifications to this unit not expressly approved by Inovonics
Wireless Corporation may void the installer's authority to operate the equipment as
well as the product warranty.
Inovonics Wireless Corporation ("Inovonics") warrants its products ("Product" or
"Products") to conform to its own specifications and to be free of defects in materials
and workmanship under normal use for a period of thirty-six (36) months from the date
of manufacture. Within the warranty period, Inovonics will repair or replace, at its
option, all or any part of the warranted Product. Inovonics will not be responsible for
dismantling and/or reinstallation charges. To exercise the warranty, the User ("User",
"Installer" or "Consumer") must work directly through their authorized distributor who
will be given a Return Material Authorization ("RMA") number by Inovonics. Details of
shipment will be arranged directly through the authorized distributor.
This warranty is void in cases of improper installation, misuse, failure to follow
installation and operating instructions, alteration, accident or tampering, and repair by
anyone other than Inovonics.
This warranty is exclusive and expressly in lieu of all other warranties, obligations or
liabilities, whether written, oral, express, or implied. There is no warranty by Inovonics
that Inovonics product will be merchantable or fit for any particular purpose, nor is
there any other warranty, expressed or implied, except as such is expressly set forth
herein. In no event shall Inovonics be liable for an incidental, consequential, indirect,
special, or exemplary damages, including but not limited to loss of profit, revenue, or
contract, loss of use, cost of down time, or interruption of business, nor any claim
made by distributor's customers or any other person or entity.
This warranty will not be modified or extended. Inovonics does not authorize any
person to act on its behalf to modify or extend this warranty.
This warranty will apply only to Inovonics Products. Inovonics will not be liable for any
direct, incidental, or consequential damage or loss whatsoever, caused by the
malfunction of Product due to products, accessories, or attachments of other
manufacturers, including batteries, used in conjunction with Inovonics Products.
Note: E-mail [email protected] for a copy of the CE Declaration of Conformity.
