KX-P1150
CN203 (Print Head)
CN204, CN300 (LED, Switches)
Pin
No. Signal
Name
Description
In/
Out
1 H6 Head Pin 6 Drive Out
2 H4 Head Pin 4 Drive Out
3 H8 Head Pin 8 Drive Out
4 H2 Head Pin 2 Drive Out
5 COMMON H2. H4, H6, H8 Out
6 NC Not Used —
7 COMMON HI, H3, H5, H7, H9 Out
8 COMMON HI, H3, H5, H7, H9 Out
9 H9 Head Pin 9 Drive Out
10 PTH Connected to Signal Ground Out
11 H7 Head Pin 7 Drive Out
12 PTH Connected to Signal Detect In
13 H5 Head Pin 5 Drive Out
14 HI Head Pin 1 Drive Out
15 H3 Head Pin 3 Drive Out
Pin
No. Signal
Name
Description
In/
Out
1 SG Signal Ground Out
2 LED Font Out
3 LED Font Out
4 LED Power Out
5 LED ON LINE Out
6 SW On Line Switch In
7 SW Font, Tear Off Switches In
8 SW LF/FF, Load Park Switches In
9 +5V +5V Out
