Chapter 7
Information Window
The information window is located at the bottom right of the EL6 Win 2 window. During file save
or file open operations, the EL6 Win 2 software error checks the file. During this procedure, the
information window will change and give details about the progress of this error check.
Each node in the tree is represented by an icon:
– Action in progress
Includes:
• Parsing program area
• Analysis of program contents
• Scanning motor modes
• Analysis of motor modes
• Data upload or download
• File save
• Cycle tree scan
– Details about an action in progress
Includes:
• Program content analysis
• Adding a new cycle
• Handshaking in progress
