Parts Included In Shifter Mounting Kit
DESCRIPTION QTY
SHIFTER MOUNT 1
REAR SHIFTER MOUNT BRACKET 1
LEFT FRONT SHIFTER MOUNT BRACKET 1
RIGHT FRONT SHIFTER MOUNT BRACKET 1
CABLE COVER PLATE 1
1/4” CAP SCREW x 3/8” LG 4
1/4" CAP SCREW x 1/2" LG *1 6
1/4" CAP SCREW x 3/4” LG *2 6
1/4” LOCK WASHER 12
1/4" FLAT WASHER 8
*3 EXTRA-THICK 1/4" FLAT WASHER 4
M8 CAP SCREW 2
M8 LOCK WASHER 2
M8 FLAT WASHER 2
PLASTIC WING NUT 2
SILICONE SEALANT 1
*1 Qty of 6 used with USDM shifter box; Qty of 2 used with JDM shifter box.
*2 Qty of 6 used with JDM shifter box; Qty of 2 used with USDM shifter box.
*3 Used only with USDM shifter box.
Tools Required
Metal Cutting Grinder
(Dremel Tool w/ EZ Lock 1.5” Cut-Off Wheels recommended)
Center Punch
Drill
9/32” Drill Bit
Socket Set – 13mm, 7/16”
7/16” Open-End Wrench
Pliers
Scissors
Tape Measure
Sharpie Marker
Note: Read all instructions before attempting installation.
If you do not believe you are qualified in performing the
necessary installation and modifications to your chassis,
please find an experienced professional who can. Karcepts,
Inc. will not be held responsible for improper modifications to
your chassis. Per the sequence of instructions provided
herein, it is your job to make certain the shifter mounting kit
fits properly before cutting a hole into your chassis.
