Parts Included In Shifter Mounting Kit
DESCRIPTION QTY
SHIFTER MOUNT 1
REAR SHIFTER MOUNT BRACKET 1
LEFT FRONT SHIFTER MOUNT BRACKET 1
RIGHT FRONT SHIFTER MOUNT BRACKET 1
CABLE COVER PLATE 1
1/4” CAP SCREW x 3/8” LG 4
1/4" CAP SCREW x 1/2" LG *1 6
1/4" CAP SCREW x 3/4” LG *2 6
1/4” LOCK WASHER 12
1/4" FLAT WASHER 8
*3 EXTRA-THICK 1/4" FLAT WASHER 4
M8 CAP SCREW 2
M8 LOCK WASHER 2
M8 FLAT WASHER *4 4
*5 M8 LOCKNUT 2
SILICONE SEALANT 1
*1 Qty of 6 used with USDM shifter box; Qty of 2 used with JDM shifter box.
*2 Qty of 6 used with JDM shifter box; Qty of 2 used with USDM shifter box.
*3 Used only with USDM shifter box.
*4 Qty of 4 used on automatic transmission chassis; Qty of 2 used on manual transmission chassis.
*5 Used only on automatic transmission chassis.
Tools Required
Die Grinder
Dremel Tool
Center Punch
Drill
Drill Bits – 9/32” & 11/32” ( 11/32” for automatic chassis only )
Socket Set – 13mm, 7/16”
7/16” Open-End Wrench
Pliers
Scissors
Sharpie Marker
Note: Read all instructions before attempting installation.
If you do not believe you are qualified in performing the
necessary installation and modifications to your chassis,
please find an experienced professional who can. Karcepts,
Inc. will not be held responsible for improper modifications to
your chassis. Per the sequence of instructions provided
herein, it is your job to make certain the shifter mounting kit
fits properly before cutting a hole into your chassis.
