TRACTOR - - MODEL NUMBER 917.273481
GROUND DRIVE
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 Transaxle (See Breakdown) 70 134683 Guide Belt Mower Drive RH
Hydro gear Mode! 336-0510 74 137057 Spacer, Axle
6 17060512 Screw 5/16-18 X 3/4 75 121749X Washer 25/32 x 1-1/4 x 16 Ga.
15 74490544 Boit Hex FIghd 5/16-18 Gr. 5 76 12000001 E-Ring
16 STD541431 Nut Lock Hex 5/16-18 77 123583X Key, Square
19 STD541437 Nut Lock Hex 3/8-16 78 121748X Washer 25/32 x 1-5/8 x 16 Ga.
22 175896 Rod, Brake 95 180825 Rod Bypass
24 73350600 Nut, Hex Jam 3/8-16 Une 96 4497H Retainer Spring 1" Zinc/Cad
25 106888X Spring, Brake Rod 116 72140608 Bolt Rdhd Sqnk 3/8-16 Unc x 1
26 19131316 Washer 120 73900600 Nut Lock Fig 3/8-16 Unc
27 76020412 Pin Cotter 1/8 X 3/4 CAD. 150 175456 Spacer Retainer
28 175765 Rod, Parking Brake 151 19133210 Washer 13/32 x 2 x 10 Ga.
29 71673 Cap Brake Parking 202 72110614 Bolt Carr Sh 3/8-16 X 1 -3/4 Gr. 5
30 169592 Bracket, Transaxle 212 145212 Nut HexFIange Lock
32 74760512 Boit Hex Hd 5/16-18 Une x 3/4 214 174735 Link Transaxle
34 175578 Shaft, Foot Pedai 215 175646 Cover Pedai Forward
35 120183X Bearing, Nyion 217 179433 Pedai Reverse Asm. w/Pad
36 19211616 Washer 218 174713 Arm Control Pedal Reverse
37 1572H Pin, Roii 219 174839 Bracket Frest Pdl Ctrl. Hyd
38 179114 Puiley, Composite 220 174711 Bracket Mtg. Pedal Control
39 74760648 Boit Fin Hex 3/8-16 Une x 3 221 STD533707 Bolt Rdhd Sqnk 3/8-16 x 3/4
41 175556 Keeper, Beit idler Fiat 222 73680700 Nut Crowniock 7/16-14 Unc
47 127783 Puiley, idler, V-Groove 223 174840 Washer Nylon 11/16 ID x .060
48 154407 Beilerank Clutch Grnd Drw StI 224 174736 Pedai Forward
49 123205X Retainer, Belt 225 174712 Arm Control Pedal Forward
50 72110612 Boit 226 174902 Bolt Pivot Spacer
51 73680600 NutCrowniock 3/8-16 Une 227 174710 Cam Reverse Pedai LT
52 73680500 Nut, Crowniock 5/16-18 Une 228 179032 Bolt Shoulder 5/16-18
53 10571OX Link, Clutch 229 176451 Washer Serrated 5/16 x .75
55 105709X Spring, Return, Clutch 231 174573 Strap Torque
56 17060620 Screw 3/8-16 X 1-1/4 241 73930400 Nut Centerlock 1/4-20 Unc
57 140294 V-Belt, Ground Drive 244 166880 Screw 5/16-18 X 5/8 Yellow
59 169691 Keeper, Center Span 250 17060612 Screw 3/8-16 X 3/4
61 17120614 Screw 3/8-16 x .875 251 17060516 Screw 5/16-18 X 1
62 8883R Cover, Pedal 253 179422 Washer .3125 X .615 x 16 Ga.
63 175410 Puiley, Engine 254 178062 Clip Retainer
64 173937 BoH Hex 7/16-20 X 4 Gr. 5" 1 - 5
T h r
65 10040700 Washer NOTE: Ail component dimensions given in U.S. inches
66 154778 Keeper Belt Engine 1 inch = 25.4 mm
