331877-0144-B1
ZTS 6000 -107.289860
850
358 ENGINE GASKET SET
524
0
1022
20
177 О
V. —-
868
Ф
51
1266
883 ОI
943 О
1266A
Liquid Sealant is Interchangeable with Rocker Cover Gasket
and/or Valve Cover Gasket
Assemblies include all parts shown in frames.
Engine Gasket and Valve Gasket Set Assemblies
Engine Briggs & Stratton Model 331877-0144-B1
Ref. No.
Part No.
Qty.
Description
Ref. No.
Part No.
Qty.
Description
3
391086s
1
Seal-Oil
850
100106
1
Sealant-Liquid
(Magneto Side)
868
690968
1
Seal-Valve
7
794114
1
Gasket-Cylinder
883
692236
1
Gasket-Exhaust
Head
943
690589
1
Seal-0 Ring
9
697109
1
Gasket-Breather
(Oil Pump Cover)
12
697110
1
Gasket-Crankcase
1022
272475s
1
Gasket-
20
791892
1
Seal-Oil
Rocker Cover
(PTO Side)
1095
794152
1
Gasket Set-Valve
51
692137
1
Gasket-Intake
1266
691917
1
Seal-0 Ring
177
691031
1
Seal-0 Ring
(Intake Elbow)
(Dipstick)
(Red)
358
796187
1
Gasket Set-Engine
1266A
697123
1
Seal-0 Ring
524
691032
1
Seal-Dipstick Tube
(Intake Elbow)
617
692138
1
Seal-0 Ring
(Intake Manifold)
691
692407
1
Seal-Governor
Shaft*
A Valve Gasket Set-Reference 1095
* Engine Gasket Set-Reference 358
• Carburetor Overhaul Kit-Reference 121
PTS-37
