Page 11 DRIVE INSTALLATION
Testing the Drive
Without connecting the drive to the computer, plug in the power cable
and turn the drive on using the main power switch on the rear of the case.
The Green Power LED and Green Frame Power LED should both come on
immediately.
If the Drive Tray is already inserted, the RED (Drive Inserted) LED
should come on and the Blue LCD Display should show both the
termperature and the fan speed (RPMs).
If the Drive Tray is not inserted, do so now, and the RED (Drive Inserted)
LED along with the Blue LCD should come on as soon as the handle is
pushed down in place.
Green Case Power LED
Green Frame Power LED Drive Activity LEDs
Key Lock
