5.
Adjust the print head position.
(1) Check the printed patterns, and use the (Left) or (Right) button to select
the pattern number that has the least noticeable streaks for column A.
Note
Refer to the samples below to select the pattern that has the least noticeable white
streaks.
(A) Less noticeable vertical white streaks
(B) Noticeable vertical white streaks
(C) Less noticeable horizontal white streaks
(D) Noticeable horizontal white streaks
(2) Repeat the same procedure to input the pattern number for each column from B
to G, and press the OK button.
(3) Confirm the message for print head alignment, and press the OK button.
The second page of print head alignment sheets will be printed.
(4) Check the printed patterns and use the (Left) or (Right) button to input the
pattern number that has the least noticeable vertical streaks for each column
from H to Q, then press the
OK button.
