21
operation
• When using the DC output, turn the Econo Switch to the OFF position.
The DC current will be below 5A if turning on the Econo Switch without
AC current output.
• To prevent the possibility of creating a spark near the battery, connect
charging cable first to the generator, then to the battery. Disconnect
cable first at the battery.
DC Applications
Example
Idling Voltage (V) Loading Voltage (V) Loading Current (A)
Opening the Econo Switch 22 12 6
Closing the Econo Switch 27 13 8.5
DC Max Output Power 37 13.5 8.5
Model I2500 I3500
Generator Rated Output 2200VA 3000VA
Frequency Power Factor
AC
1.0 2200W 3000W
0.4-0.75 0-720W-1350W 0-920W-1725W
DC
100W
(12V/8.3A)
