Weather System COB User Manual Rev. A Copyright (c) 2014 Blizzard Lighting, LLC
DMX Values In-Depth (8-Channel Mode)
Channel Value What It Does
1 000 <--> 255 Red - Fixtures 1+2 (0% <--> 100%)
2 000 <--> 255 Green - Fixtures 1+2 (0% <--> 100%)
3 000 <--> 255 Blue - Fixtures 1+2 (0% <--> 100%)
4 000 <--> 255 Red - Fixtures 3+4 (0% <--> 100%)
5 000 <--> 255 Green - Fixtures 3+4 (0% <--> 100%)
6 000 <--> 255 Blue - Fixtures 3+4 (0% <--> 100%)
7 000 <--> 255 Strobe (slow <--> fast)
8 000 <--> 255 Dimmer (0% <--> 100%)
DMX Values In-Depth (7-Channel Mode)
Channel Value What It Does
1 000 <--> 255 Red - Global (0% <--> 100%)
2 000 <--> 255 Green - Global (0% <--> 100%)
3 000 <--> 255 Blue - Global (0% <--> 100%)
4 000 <--> 009
010 <--> 019
020 <--> 029
030 <--> 039
040 <--> 049
050 <--> 059
060 <--> 069
070 <--> 079
080 <--> 089
090 <--> 099
100 <--> 109
110 <--> 119
120 <--> 129
130 <--> 139
140 <--> 149
150 <--> 159
160 <--> 169
170 <--> 179
180 <--> 189
190 <--> 199
200 <--> 209
210 <--> 219
220 <--> 229
230 <--> 239
240 <--> 255
No Function
Red
Yellow
Green
Cyan
Blue
Purple
White
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Program 8
Program 9
Program 10
Program 11
Program 12
Program 13
Program 14
Program 15
Program 16
Sound Active Mode (ch. 5 controls mic sensitivity)
5 000 <--> 255 Program Speed (0% <--> 100%)
6 000 <--> 255 Strobe (slow <--> fast)
7 000 <--> 255 Dimmer (0% <--> 100%)
