Weather System COB User Manual Rev. A Copyright (c) 2014 Blizzard Lighting, LLC
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
Set the DMX Starting Address
1.) The default mode for the fixture is DMX, which appears as d001 on the LED
readout. To select a different DMX address, hit the button and use
the buttons to select the your desired starting DMX address
ranging from d001 - d512 then hit again to confirm your choice.
DMX Channel Mode
1.) To change the DMX channel mode, use the button to scroll to
d001 and hit the button. Push the button again and use
the buttons to scroll through your choices of 2-ch, 3-ch, 4-ch,
7-ch, 8-ch, 14ch or 15ch. Press to confirm your choice.
Slave Mode
1.) To use as a slave unit, simply use the button to scroll to SLAu.
This Weather System™ COB will now be in slave mode and follow the master
unit, which is the 1st Weather System™ COB in the DMX chain.
Static Colors, Auto Mode, & Sound Active Modes:
Allows a single or Master/Slaved units to run factory installed programs at user selectable
speeds.
Static Colors
1.) To use one of the 7 built-in static colors (8 is off), use the button
to scroll to Pr-1, and hit . Use the buttons to scroll
through the static color choices:
1 --r (red) 2 -r9 (yellow) 3 --9 (green) 4 -9b (teal)
5 --b (blue) 6 -rb (magenta) 7 r9b (white) 80FF (off)
2.) Push the button to confirm your choice. Now you can adjust the
strobe speed by selecting the strobe speed adjustment settings of FS01 - FS99
(slow <--> fast).
Built-in Programs
1.) To set the fixture to run a single built-in program, use the button
to scroll to Pr--, and press the button. Then use the
buttons to scroll through the built-in program choices of Pr02-Pr14 and push
the button to confirm your choice. Now you can adjust the speed
of the program by using the buttons and choose from SP01 -
SPFL (slow <--> fast), and push the button. To conclude setup, you
now have the option to adjust the strobe speed of the program by selecting the
strobe adjustment settings of FS01 - FS99 (slow <--> fast).
Auto Mode
1.) To set the fixture to run in auto mode, use the button to scroll to
AUTO, and hit . You can now adjust the speed by using the
DOWN> buttons and choose from SP01 - SPFL (slow <--> fast). To confirm
your choice press the button You can now adjust the strobe speed by
selecting the strobe adjustment settings of FS01 - FS99 (slow <--> fast).
