Operating features – Wood’s Powr-Grip PT10FS10TDC User Manual
Page 5
Rev 10.0/4-13
3
PT10HV11FDC: #35144
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard PT10HV11FDC shown.
1 LIFT SHACKLE
8 POWER SWITCH
16 MOVABLE CONTROL PENDANT
2 VACUUM RESERVE TANK
9 BATTERY GAUGE
17 HOIST PENDANT BASKET
3 BATTERY CHARGER
10 BATTERY TEST BUTTON
18 AIR FILTER
4 TILT ACTUATOR
11 VACUUM PAD
19 PAD FRAME
5 Enclosure with VACUUM PUMP(S)
12 PAD SHUTOFF
20 VACUUM GAUGE
6 Enclosure with VACUUM SWITCH
13 CONTROL HANDLE
21 Enclosure with BATTERY
7 VACUUM LIFT LIGHT
14 TILT TOGGLE SWITCH
22 LIFT BAR
15 APPLY/RELEASE SWITCH
